Equipment Used
- 60 Ton Minster
- 300 Ton Minster
Expertise
- Engineering
- Tool Making
- Design
- Machining
- Heat Treat
- Grinding
- Wire EDM
Technical Specifications
Overall Part Dimensions: From not much larger than a penny to the size of a softball.
Estimated Part Weight: A few ounces to over 1 lb.
Materials Used
- High Carbon Steel
- 316L Stainless Steel
In Process Inspection / Testing
CMM
Industry
- Agriculture
- Food & Beverage
- Mechanical Power Transmission
- Oil Fields
- Mining Industries
Volume
300 pcs – 100,000 pcs per order.
Delivery / Turn-Around Time
Tooling Produces over 1 year’s time. Lead time on parts 2 – 5 days.
Location
Northern Illinois
Product Name
Precision Roller Chain
Value Proposition
- Shortened Lead Times
- Increased Material Quality
- Made in the USA
Summary
A Mechanical Power Transmissions producer was getting Metal Stamped products from overseas. This caused many issues for them including very lengthy lead times, raw materials that did not meet specs, and ANSI Standard Dimensional Issues. Die Makers Mfg worked with the customer and rebuilt 60+ Compound and Progressive tools to produce high quality parts in the USA while holding +/- .0003 Tolerances.
